ZHZ

9007-LOW VOLTAGE SHUTOFF (ZHZ)

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
Continuously.

- Set Condition:
The Warm Water Auxiliary Heating 2 Control Unit receives less than 10 volts.





Diagnostic Test

1. WARM WATER AUXILIARY HEATING 2 CONTROL UNIT
The Warm Water Auxiliary Heating 2 Control Unit is receiving less than 10 volts.
View repair.

Repair

- Repair low voltage condition. If low voltage is not present, replace the Warm Water Auxiliary Heating 2 Control Unit.
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests.
