90AA

90AA-RIGHT VENT WINDOW - HIGH TEMPERATURE OPERATION - BCM

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
Continuously

- Set Condition:
When the heat in the Right Vent Window Motor exceeds the specified tolerance, this code will set.





Diagnostic Test

1. TEST FOR INTERMITTENT CONDITION
With the scan tool, record and erase DTC's
Operate the Right Vent Window Motor in both directions several times.
Cycle the ignition from on to off.
Turn the ignition on.
With the scan tool, read DTC's.
Does the scan tool display 90AA-RIGHT VENT WINDOW - HIGH TEMPERATURE OPERATION?

Yes

- Go To 2

No

- The conditions that caused this code to set are not present at this time. Check for any binding conditions in the window and using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests

2. WINDOW MOTOR
Gain access to the vent window motor assembly.
Check for any binding conditions in the window.
Was any binding conditions found?

Yes

- Repair or replace the cause of the binding condition.
- Perform BODY VERIFICATION TEST - VER 1.Verification Tests.

No

- Replace the Vent Window Motor.
- Perform BODY VERIFICATION TEST - VER 1.Verification Tests.
