Removal

3.0L DIESEL
1. Remove the drive belt.
2. Siphon the power steering system.
3. Remove the pressure line at the pump.
4. Remove the supply line at the pump.
5. Remove the pump mounting bolts.




6. Remove the pump (1) from the vehicle.
7. Remove pulley (4) if needed.
8. Transfer the brackets (2) if necessary.
