Washer Fluid Level Switch: Diagrams

Component ID: 552
Component : SWITCH-WASHER-FLUID LEVEL

Connector:
Name : SWITCH-WASHER FLUID LEVEL
Color :
# of pins : 2




Pin Description Circuit
1 - 595 20BR/DG
2 - 596 20DB/WT
