Relay-Fuel Pump

Component ID: 317
Component : RELAY-FUEL PUMP

Connector:
Name : RELAY-FUEL PUMP
Color :
# of pins : 5




30 FUSED B(+) INTERNAL
85 FUEL PUMP RELAY CONTROL 1776 18RD/WT
85 FUEL PUMP RELAY CONTROL 1258 18RD/WT
86 FUEL ENGINE CONTROL RELAY OUTPUT INTERNAL
87 FUEL PUMP RELAY OUTPUT 3820 12RD/DG
87A - -
