Solenoid-Camshaft Position 1/1


Component ID: 508
Component : SOLENOID-CAMSHAFT POSITION 1/1

Connector:
Name : SOLENOID-CAMSHAFT POSITION 1/1
Color : BLACK
# of pins : 2




Pin Description Circuit
1 CMP 1/1 CONTROL 1610 18YL/DB
2 FUSED MAIN RELAY OUTPUT U795 18BK/WT
