Actuator-Recirculation Door

Component ID: 13
Component : ACTUATOR-RECIRCULATION DOOR

Connector:
Name : ACTUATOR-RECIRCULATION DOOR
Color : GRAY
# of pins : 2




Pin Description Circuit
1 - 2391 20 DG
Pin Description Circuit
1 - 2394 20 DG
2 - 2392 20 OR
2 - 2393 20 OR
