Wipers/Washers

9084-RAIN LIGHT SENSOR NOT LEARNED-RCM

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

With the ignition on.

- Set Condition:

The RCM detects that the Rain Light Sensor is not learned.






Diagnostic Test

1. REPROGRAM THE RAIN LIGHT SENSOR

With the scan tool, read RCM DTCs.

Is DTC: 9084-RAIN LIGHT SENSOR NOT LEARNED-RCM active?

Yes

- The Rain Light Sensor must be reprogrammed/learned. Check the applicable service information for reprogramming.
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests

No

- Test complete.
