Restraints

9014-DRIVERS SEAT BELT SENSE CIRCUIT PERFORMANCE





For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

With the ignition on.

- Set Condition:

This code occurs only in combination with other active DTC's.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.

Diagnostic Test

1. VERIFY OTHER ACTIVE DTC

NOTE: Ensure the battery is fully charged.

Turn the ignition on.

With the scan tool, perform a ORC reset.

With the scan tool, read the active ORC DTC.

Does the scan tool display any other Driver Seat Belt Switch active DTCs?

Yes

- Diagnose and repair the DTC's.

No

- Replace the Occupant Restraint Controller (ORC).
- Perform *RESTRAINT VERIFICATION TEST. Verification Tests
