Auxiliary Electrical Heating Module Internal (AEHM)

9001-AUXILIARY ELECTRICAL HEATING MODULE INTERNAL (AEHM)

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

Continuously.

- Set Condition:

The Auxiliary Electrical Heating Module (AEHM) detects an internal failure.






Diagnostic Test

1. AUXILIARY ELECTRICAL HEATING MODULE

The Auxiliary Electrical Heating Module (AEHM) is reporting internal errors.

View repair.

Repair

- Replace the Auxiliary Electrical Heating Module (AEHM).
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests
