D700

D700-CD MECHANICAL ERROR-TRAY 1-CDC

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:
- Continuously with the ignition on and the CD player turned on.
- Set Condition:
- The code will set if a CD that is not formatted as a CD is installed in the CD player.






Diagnostic Test

1. CD PLAYER

Replace the problem CD with a good, clean, unscratched CD.

Turn the CD player on.

With the Scan Tool, read DTC's.

Does the Scan Tool display: D700-CD MECHANICAL ERROR-TRAY 1-CDC?

Yes

- Eject the inoperative CD and replace the CD.
- Perform the BODY VERIFICATION TEST - VER 1. Verification Tests

No

- Test Complete.
