Power Locks

900E-DOOR LOCK SWITCH STICKING IN LOWER POSITION - SBM





For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

Continuously

- Set Condition:

When the door lock switch is held in the lower position for longer than 25 seconds.






Diagnostic Test

1. TEST FOR INTERMITTENT CONDITION

With the scan tool, record and erase DTC's

Close all doors and operate the Door Lock Switch in all positions several times.

Cycle the ignition from on to off.

Turn the ignition on.

With the scan tool, read DTC's.

Does the scan tool display 900E-DOOR LOCK SWITCH STICKING IN LOWER POSITION?

Yes

- Replace the Switch Bank Module.
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests

No

- The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform BODY VERIFICATION TEST - VER 1. Verification Tests
