Solenoid Supply/Watchdog
Symptom:SOLENOID SUPPLY/WATCHDOG
When Monitored and Set Condition
When Monitored: Always monitored with system active at each ignition cycle.
Set Condition: During the power up of the TCM, it tests the ability of the external watchdog to shut down the Solenoid Supply driver.
POSSIBLE CAUSES
- SOLENOID SUPPLY CIRCUIT SHORT TO OTHER CIRCUITS
- SOLENOID DTCS PRESENT
- TCM - SOLENOID SUPPLY WATCHDOG
