A/C Compressor Control Shorted Low (Active)

Test 1 - Test 3:

Test 4:

SYMPTOM
A/C COMPRESSOR CONTROL SHORTED LOW (ACTIVE)

POSSIBLE CAUSES
- A/C compressor clutch
- A/C compressor clutch control circuit shorted to ground
- A/C compressor clutch control circuit shorted to ground circuit
- A/C compressor clutch control circuit shorted to sensor ground circuit
- Automatic temperature control (ATC)
