Radiator: Service and Repair

Radiator

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure. Failure to follow this instruction may result in serious personal injury.

Refer to: Engine Cooling System Health and Safety Precautions. Engine Cooling System Health and Safety Precautions

2. Refer to: Cooling Fan Motor and Shroud.
3. Torque: 7 Nm







4. Torque: 6 Nm







5. Torque: 6 Nm







Installation

1. to install, reverse the removal procedure.
