Side Marker Lamp - Rear

Side Marker Lamp - Rear









Removal and Installation

1. NOTE: Using a suitable thin-bladed tool, separate the rear of the side marker lamp from the bumper cover first.

Remove the rear side marker lamp.

- Disconnect the electrical connector.

2. To install, reverse the removal procedure.
