Pinpoint Test L: The Smart Unlock Does Not Operate Correctly

Locks, Latches and Entry Systems







Pinpoint Tests

Pinpoint Test L: The Smart Unlock Does Not Operate Correctly

NOTE: It is possible to lock the vehicle with the keys in the ignition lock cylinder if the doors are locked with the Remote Keyless Entry (RKE) transmitter, manually locked with the lock button on the door, or by locking the driver door with a key.

Normal Operation

The smart unlock feature unlocks the driver door if the key is in the ignition lock cylinder and the driver door is open when the vehicle is locked with the door lock control switch. The smart unlock feature requests the driver door be unlocked one second after these conditions occur. The smart unlock feature unlocks the driver door only if the Transmitter Identification Code (TIC) programming modes are not active.

This pinpoint test is intended to diagnose the following:

- Smart Junction Box (SJB)



PINPOINT TEST L: THE SMART UNLOCK DOES NOT OPERATE CORRECTLY

-------------------------------------------------
L1 CHECK THE COURTESY LAMP OPERATION


- Open and close the driver door.
- Do the courtesy lamps operate correctly?

Yes
GO to L2.

No
REFER to Courtesy Lamp. Testing and Inspection

-------------------------------------------------
L2 CHECK THE KEY-IN-IGNITION WARNING CHIME


- Insert the key in the ignition switch.
- Open the driver door.
- Does the key-in-ignition warning chime work correctly?

Yes
GO to L3.

No
REFER to Instrument Panel, Gauges and Warning Indicators.

-------------------------------------------------
L3 CHECK FOR CORRECT SJB OPERATION


- Disconnect all SJB connectors.
- Check for:
- corrosion
- damaged pins
- pushed-out pins
- Connect all SJB connectors and make sure they seat correctly.
- Operate the system and verify the concern is still present.
- Is the concern still present?

Yes
INSTALL a new SJB. TEST the system for normal operation.

No
The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

-------------------------------------------------
