Front

Fig. 12 Stabilizer Bar Installation:

Fig. 13 Stabilizer Bar Link Installation:

1. Raise and properly support vehicle.
2. Remove wheel and tire assembly.
3. Remove stabilizer bar link assembly from lower control arm, Fig. 12.
4. Remove mount bolt from stabilizer bar bushing.
5. Remove stabilizer bar from vehicle.
6. Reverse procedure to install. Tightening to specifications. Tighten stabilizer bar link nut until .79 inch of threads protrude above nut, Fig. 13.
