Front Bumper Reinforcement: Service and Repair

FRONT BUMPER

Removal and Installation
1. Remove the front bumper cover.







2. Remove the front bumper.
1 Remove the four front bumper nuts (two each side).
2 Remove the front bumper.

3. To install. reverse the removal procedure.
