Rear Door Glass Adjustment

Rear Door Glass Alignment:

1. Remove door trim panel.
2. Loosen screw holding scissor channel to door panel at rear of access hole.
3. Loosen bolt holding support brace to door panel above access hole.
4. Loosen nut holding scissor channel to support brace.
5. Position glass in run weatherstrips to achieve smooth operation and proper fit.
6. Secure all fasteners and install trim panel.
