Radiator Cooling Fan - Control Chart Revision

NO.:
07-05-92

GROUP:
Cooling

DATE:
Nov. 16, 1992



SUBJECT:
Service Manual Revision Radiator Cooling Fan



MODELS:

1993 (LH) Concorde/Intrepid/Vision


DISCUSSION:

The radiator fan control chart has been revised to eliminate the separate 3.3L and 3.5L designations and add an A/C compressor pressure column. Please insert the corrected page in the manual. The affected service manual is:


MANUAL NUMBER PAGE





Concorde/Intrepid/Vision 81-270-3140 7-18


POLICY:
Information only
