Occupant Restraint Controller (ORC)

B222A-00-VEHICLE LINE MISMATCH

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
With the ignition on. The module's on board diagnostics continuously performs internal circuit tests.

- Set Condition:
This DTC will set if the module identifies an out of range internal circuit.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Restraints System Pre-Diagnostic Procedure.
REPLACE OCCUPANT RESTRAINT CONTROLLER
1. Turn the ignition on.
2. With the scan tool, erase and read ORC DTCs.

WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury.

When this code is set, view repair.

Repair

- Replace the Occupant Restraint Controller. Occupant Restraint Controller - Removal.
- Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Restraints System Verification Test.
