B1424

B1424-00-IMPROPER DVD - WRONG REGION

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously with the ignition on and the Radio/DVD player turned on.

- Set Condition:
The code will set if a DVD is not formatted for the proper region or the Radio/DVD player is programmed for the incorrect region.





1. CHECK THE DVD
1. Replace the problem DVD with a DVD formatted for the proper region.
2. Turn the Radio/DVD player on.
3. With the scan tool, read the Telematics Gateway (TGW) DTCs.

Does the scan tool display active: B1424-00-IMPROPER DVD - WRONG REGION?

Yes

- Go To 2

No

- Test Complete.

2. CHECK THE TELEMATICS GATEWAY (TGW)
1. With the scan tool, verify the TGW is programmed for the proper region.
2. With the scan tool, read DTCs.

Does the scan tool display active: B1424-00-IMPROPER DVD - WRONG REGION?

Yes

- Eject the inoperative DVD and replace the TGW. Telematics Gateway Module - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test

No

- Test Complete.
