Water Pump - Removal

GAS ENGINE










1. Remove the accessory drive belt Serpentine Accessory Drive Belt - Removal.
2. Raise vehicle Maintenance.
3. Remove accessory drive belt splash shield.
4. Drain cooling system Service and Repair.
5. Remove screws attaching water pump pulley (1). Remove pulley (1).
6. Remove water pump mounting bolts (2).
7. Remove water pump (3).
