U0415

U0415-IMPLAUSIBLE DATA RECEIVED FROM ABS

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously while the system is active.

- Set Condition:
Implausible data has been received over the bus from the Anti-lock Brake Module.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Pre-Diagnostic Troubleshooting Procedure.

1. ACTIVE DTC

NOTE: Diagnose all CAN B and C communication DTCs before continuing.

1. Turn the ignition on.
2. With a scan tool, view DTCs.

Is the status Active for this DTC?

Yes

- Go To 2

No

- Performing the INTERMITTENT CONDITION diagnostic procedure. Intermittent Condition Test.

2. ABS COMMUNICATION RELATED DTCs IN OTHER MODULES
1. With a scan tool check for ABS communication related DTCs in other modules on the CAN Bus.

Are there any ABS communication related DTCs in other modules on the CAN Bus at this time?

Yes

- Replace and program the Anti-Lock Brake Module.
- Perform the ABS VERIFICATION TEST. ABS Verification Test.

No

- Replace and program the Powertrain Control Module (PCM).
- Perform the PCM VERIFICATION TEST. Powertrain Verification Test.
