Left Engine Mount

INSTALLATION





1. Position mount (2) in place.
2. Install left mount to frame rail bolts (1) and torque to 75 Nm (55 ft. lbs.).
3. Install mount through bolt (3) and torque to 100 Nm (74 ft.lbs.).
4. Remove jack.




5. Install PCM mounting bracket.
6. Install PCM (1).
7. Connect negative cable to battery (3).




8. Install air cleaner housing (1) and air cleaner inlet (2).
