B2222

B2222-SATELLITE RADIO RECEIVER INTERNAL

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:
- With the ignition on.
- Set Condition:
- The Satellite Radio Receiver detects a software checksum test failure.





Diagnostic Test

1. REPLACE THE SATELLITE RADIO RECEIVER

When this code is set, the Satellite Radio must be replaced.

Repair

- Replace the Satellite Radio Receiver.
