Vehicle Theft Security

B210E-BATTERY VOLTAGE HIGH





For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

With the ignition switch on.

- Set Condition:

The SKREEM has detected the Fused (B+) input voltage above a calibrated value.





Diagnostic Test

1. DETERMINING IF DTC IS CURRENT

NOTE: Diagnose and repair all Powertrain DTCs before continuing.

Turn the ignition on.

With the scan tool, record and erase the SKREEM DTCs.

Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle.

Using the scan tool, read the SKREEM DTCs.

Does the DTC reset?

Yes

- Replace and program the SKREEM.
- Perform SKREEM VERIFICATION TEST. Vehicle Theft Security Verification Tests

No

- Perform SKREEM VERIFICATION TEST. Vehicle Theft Security Verification Tests
