Home >> Dodge >> 2000 >> Stratus L4-2.0L VIN C >> Repair and Diagnosis >> A L L Diagnostic Trouble Codes ( DTC ) >> Testing and Inspection >> Manufacturer Code Charts >> Wiper/Washer >> Wipers Operate/High Speed Only

Wipers Operate/High Speed Only

Test 1 - 3:




SYMPTOM
WIPERS OPERATE/HI SPEED ONLY

POSSIBLE CAUSES
- DEF BCM/HI-LO wiper relay
- DEF HI/LO wiper relay
- HI/LO wiper relay control CKT SH/GND
