Instrument Panel Top Cover Replacement

REMOVAL
1. Open glove box door.
2. Remove right end cap and remove screw at right end.
3. Remove left and right A-pillar moldings by disengaging the top christmas tree fasteners and then pulling the moldings out vertically.

Top Cover:

4. Lift the right rear edge of top cover to disengage the clips along the rear edge. Proceeding from right to the left side. Do not use a nylon trim stick, to avoid potential damage.
5. Lift rear edge and slide top cover rearward disengaging clips and remove cover.

INSTALLATION
- For installation, reverse the above procedures. Ensure the two center clips are engaged first. Place thumb in VIN opening and pull towards pad to ensure VIN alignment. If a gap exist between the top cover and pad after installation check for a damaged clip. The clip must be removed and replaced.
