Ball Joint: Testing and Inspection

Fig. 9 Ball Joint Wear Inspection:

With the weight of the vehicle resting on the road wheels, grasp the grease fitting as shown and with no mechanical assistance or added force, attempt to move the grease fitting.

If the ball joint is worn, the grease fitting will move easily If movement is noted, replace the ball joint.
