U1424

U1424-IMPLAUSIBLE ENGINE TORQUE RECEIVED

For a complete wiring diagram, refer to the Wiring Information.

Theory of Operation

This message is used by the TCM as part of the torque management strategy between the PCM and the TCM.

When Monitored:
- Continuously with the ignition on.

Set Condition:
- When the message is not received or stays unchanged for 10.5 seconds or more for two consecutive ignition cycles.






Always perform the AS68RC Pre-Diagnostic Troubleshooting procedure before proceeding. AS68RC Pre-Diagnostic Troubleshooting Procedure

1. CHECK FOR TIPM CAN BUS DTCs
1. With the scan tool, read TIPM DTCs.

Are there any TIPM CAN BUS DTCs present?

Yes

- Refer to DTC Based Diagnostics and perform the appropriate diagnostic procedure.
- Perform AS68RC TRANSMISSION VERIFICATION TEST. AS68RC Transmission Verification Test

No

- Go To 2

2. CHECK IF ENGINE DTCs ARE PRESENT
1. With the scan tool, read engine DTCs.

Are there any engine DTCs present?

Yes

- Refer to DTC Based Diagnostics and perform the appropriate diagnostic procedure.
- Perform AS68RC TRANSMISSION VERIFICATION TEST. AS68RC Transmission Verification Test

No

- Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM.
- Perform AS68RC TRANSMISSION VERIFICATION TEST. AS68RC Transmission Verification Test
