B2599-96

B2599-96-DOOR MODULE FRONT RIGHT - COMPONENT INTERNAL FAILURE

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
At all times.

- Set Condition:
When the door module senses an internal fault, this code will set.





TEST FOR INTERMITTENT CONDITION
1. Turn the ignition on.
2. With the scan tool, record and erase the DTCs.
3. Operate the Passenger Window up and down several times.
4. Wait 30 seconds.
5. With the scan tool, read the active DTCs.

Does the scan tool display B2599-96-DOOR MODULE FRONT RIGHT - COMPONENT INTERNAL FAILURE ?

Yes

- Replace the Door Module.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- The conditions that caused this code to set are not present at this time. If this code ever repeats, replace the door module.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
