B1D00

B1D00-2A-MIRROR FOLD SWITCH INPUT STUCK

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
When the mirror fold operation is requested.

- Set Condition:
If the Driver Door Module detects that the Mirror Switch is stuck in the same position for more than 30 seconds.





VERIFY IF DTC B1D00-2A MIRROR FOLD SWITCH INPUT STUCK IS ACTIVE
1. Turn the ignition on.
2. With the scan tool, erase the DTCs.
3. Press the Mirror Fold Switch in both directions several times.
4. Cycle the ignition from on to off three times.
5. Turn the ignition on.
6. With the scan tool, read the active DTCs.

Does the scan tool display active: B1D00-2A MIRROR FOLD SWITCH INPUT STUCK?

Yes

- Replace the Drivers Door Window/Mirror Switch Assembly.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit. Repair as necessary.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
