B0092

B0092-49-LEFT SIDE ACCELERATION SENSOR 2 - INTERNAL ELECTRONIC FAILURE





For a complete wiring diagram, refer to the Wiring Information.

Theory of Operation

The location of this left side impact sensor 2 is located in the Left C-pillar just past the second row seating.Impact Sensor - Description. Impact sensors perform internal self-tests and communicate the sensors status using power supplied by the Occupant Restraint Controller (ORC). The sensor communicates this internal failure message using the sensor signal circuit. If the scan tool shows this DTC has a Stored history of setting then the left side impact sensor is to be replaced.

- When Monitored:
Impact sensors perform the self-test for internal circuitry at power up during the initialization process, and continuously through the ignition cycle every 10 ms.

- Set Condition:
This Diagnostic Trouble Code (DTC) will sets if the ORC receives an internal failure message from the Impact Sensor. The DTC will be latched on for the duration of the ignition cycle.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Restraints System Pre-Diagnostic Procedure.

NOTE: If the scan tool shows this DTC has a Stored history of setting then the left side impact sensor is to be replaced.
VERIFY ACTIVE DTC

NOTE: Make sure the battery is fully charged.

1. Turn the ignition on.
2. With the scan tool, read ORC DTCs.

Does the scan tool display an active B0092-49-LEFT SIDE ACCELERATION SENSOR 2 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored?

Yes

- WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

- Replace the Left Side Impact Sensor 2. Side
- Perform the RESTRAINT SYSTEM VERIFICATION TEST. Restraints System Verification Test.

No (Did not set a active or stored DTC B0092-49- LEFT SIDE SATELLITE SENSOR 2- INTERNAL ELECTRONIC FAILURE)

- Perform the RESTRAINT SYSTEM INTERMITTENT TEST. Restraints System Intermittent Condition Test
