Speaker - Installation

INSTALLATION






CENTER FRONT SPEAKER

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the speaker cover.
4. Connect the battery negative cable.

FRONT DOOR MIDRANGE SPEAKERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners
3. Install the door trim panel.
4. Connect the battery negative cable.

FRONT DOOR TWEETERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the door trim panel.
4. Connect the battery negative cable.

REAR SIDE WALL MIDRANGE SPEAKERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the rear quarter trim panel. Quarter Trim Panel - Installation
4. Connect the battery negative cable.

REAR SIDE WALL TWEETERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the rear quarter trim panel. Quarter Trim Panel - Installation
4. Connect the battery negative cable.

SIDE WALL MIDRANGE SPEAKERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the rear quarter trim panel. Quarter Trim Panel - Installation
4. Connect the battery negative cable.

SIDE WALL TWEETERS

1. Connect the electrical connector and install the speaker.
2. Install the mounting fasteners.
3. Install the rear quarter trim panel. Quarter Trim Panel - Installation
4. Connect the battery negative cable.
