Radio

D000-RADIO INTERNAL-RADIO

For a complete wiring diagram, Refer to the Wiring Information Electrical Diagrams.

- When Monitored:
Whenever the radio is awake.

- Set Condition:
When the radio detects an internal fault.





1. TEST FOR INTERMITTENT CONDITION
1. Turn the ignition on.
2. With the scan tool, record and erase DTC's.
3. With the scan tool, read DTC's.

Does the scan tool display D000-RADIO INTERNAL-RADIO?

Yes

- Go To 2

No

- The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform BODY VERIFICATION TEST. Body Verification Test.

2. RADIO
1. This is an internal radio fault code.

Is the code active?

Yes

- Replace the radio.
- Perform BODY VERIFICATION TEST. Body Verification Test.

No

- Test Complete.
- Perform BODY VERIFICATION TEST. Body Verification Test.
