Speaker-Tweeter-Left Rear

Component ID: 576
Component : SPEAKER-TWEETER-LEFT REAR

Connector:
Name : SPEAKER-TWEETER-LEFT REAR
Color : BLACK
# of pins : 2




Pin Circuit Description
1 U282 18BR/WT -
2 U281 18BR/RD -
