Speaker-Right Door

Component ID: 571
Component : SPEAKER-RIGHT DOOR

Connector:
Name : SPEAKER-RIGHT DOOR
Color :
# of pins : 2




Pin Circuit Description
1 5166 14BR/VT -
Pin Circuit Description
1 932 14BR/OR -
2 5167 14BR/DG -
2 933 14BR/DB -
