Trans Temp Sensor Shorted
Symptom:TRANS TEMP SENSOR SHORTED
When Monitored and Set Condition
When Monitored: Always monitored with system active
Set Condition: Temperature sensor input below a threshold, failed temperature sensor, short to ground, TCM
POSSIBLE CAUSES
- TEMP SENSOR - P/N SWITCH CIRCUIT SHORT TO GROUND
- TEMP SENSOR - P/N SWITCH CIRCUIT SHORT TO OTHER CIRCUITS
- TCM - P/N SWITCH CIRCUIT
- TRANSMISSION TEMPERATURE SENSOR
- TCM - TRANS TEMP SENSOR SHORTED
- TRANSMISSION TEMP SENSOR - P/N SWITCH
Test 1 - Test 2:
