Home >> Dodge or Ram Truck >> 2005 >> Sprinter 3500 L5-2.7L DSL Turbo >> Repair and Diagnosis >> A L L Diagnostic Trouble Codes ( DTC ) >> Testing and Inspection >> P Code Charts >> P2353

P2353

Test 1 - 2:




Test 3:






SYMPTOM
P2353 - O2 SENSOR PLAUSIBILITY

POSSIBLE CAUSES
- Checking circuit integrity
- O2 sensor
- Intermittent condition
