Dynamics Sensor - Installation

INSTALLATION






1. Install the dynamics sensor (2) over the studs mounted to the floor pan tunnel.

2. Install the two mounting nuts (1). Tighten the nuts to 9 Nm (80 in. lbs.).

3. Connect the wiring harness connector (3) to the dynamics sensor (2).





4. Install the center console Shifter Housing - Installation.

5. Connect the battery negative cable to the battery post. It is important that this be performed properly.

6. Perform the Verification Test and clear any faults Verification Tests.
