Removal

REMOVAL










CAUTION:
Use of pliers on draincock is not recommended. Damage may occur to radiator or draincock.

NOTE:
It is not necessary to remove draincock during a routine coolant drain.

1. Drain the cooling system Service and Repair.

2. Open the draincock by turning it counterclockwise until it stops.

3. Turn the draincock back (clockwise) 1/8 turn.

4. Pull the draincock from the radiator tank.
