Speaker - Installation

INSTALLATION






SPEAKER-FRONT DOOR

1. Connect the electrical connector and install the speaker.

2. Install the speaker mounting fasteners.

3. Install the door trim panel. Front Door Trim Panel - Installation.

4. Connect the battery negative cable.

SPEAKER-INSTRUMENT PANEL





1. Connect the electrical connector and install the speaker.

2. Install the speaker mounting fasteners.

3. Install the speaker grille (1).

4. Connect the battery negative cable.

SPEAKER-REAR QUARTER PANEL





1. Connect the electrical connector and install the speaker.

2. Install the speaker mounting fasteners.

3. Install the rear quarter trim panel. Quarter Trim Panel - Installation.

4. Connect the battery negative cable.

SPEAKER-REAR SHELF





1. Connect the electrical connector and install the speaker.

2. Install the speaker mounting fasteners.

3. Install the rear shelf trim panel. Rear Shelf Panel - Installation.

4. Connect the battery negative cable.
