Axle Shaft Seal - Removal

REMOVAL





1. Remove halfshaft(s).Half Shaft - Removal
2. Using suitable screwdriver (1), remove axle shaft seal (2).
3. Visually inspect halfshaft seal journal for damage (excessive seal groove, nicks, scratches, etc.). Replace halfshaft if necessary.
