Vented Seat Motor - Installation

INSTALLATION

NOTE: On all models, the front passenger seat contains an Occupant Detection Sensor (ODS) to provide information to the Occupant Restraint Controller (ORC) Occupant Restraint Controller - Description .

NOTE: Driver seat shown in illustrations. Passenger seat similar.






NOTE: Illustration shown with seat cushion and cover removed from view for clarity. It is not necessary to completely remove the seat bottom cushion and cover from the seat bottom pan to service the vented seat motor.

1. Position the vented seat motor (1) underneath the seat bottom pan (2) and engage the four plastic retainers (3 and 4) to the pan. Be sure the retainers are fully engaged.





2. Connect the vented seat pad (2) to the vented seat motor and engage the four retaining tabs that secure the pad to the motor. Be sure the retaining tabs are fully engaged.
3. Install the seat bottom cushion and cover (1) onto the seat bottom pan (3) Seat Cushion Cover - Installation.





4. Connect the electrical connectors (2 and 3) for the vented seat motor (1), located under the seat bottom pan (4).
5. When servicing the driver seat, install the memory seat module and bracket Memory Seat Module - Installation.
6. When servicing the passenger seat, install the heated seat module and bracket Heated Seat Module - Installation.
7. Install the seat Front Seat - Installation.
8. Reconnect the negative battery cable.
9. Verify proper vented seat system operation.
