Body Cladding - Removal

REMOVAL





1. Raise and support the vehicle.
2. Remove the wheels from the side of the vehicle being serviced Tires And Wheels - Removal
3. Remove the pop rivets (2 and 5) from the front fender (1) and rear quarter panel (6).
4. Remove the rear body side cladding (4) by disengaging the cladding retaining clips from the rocker panel (7).
5. Remove the front body side cladding (3) by disengaging the retaining clip from the front fender.
