U0208

U0208-00-LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
With the ignition on.

Battery voltage between 10 and 16 volts.

Body Control Module (BCM) is configured correctly.

- Set Condition:
Bus messages not received from the Heated Seat Control Module for approximately two to five seconds.





VERIFY DTC IS ACTIVE
1. Turn the ignition on.
2. With the scan tool, read the active DTCs.

Does the scan tool display; U0208-00-LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE as active?

Yes

- Perform the U0208-00-Lost Communication with Heated Seat Control Module diagnostic procedure.

No

- Perform the Stored Lost Communication DTCs diagnostic procedure. Stored Lost Communication DTCs
