U0168

U0168-00-LOST COMMUNICATION WITH INTRUSION TRANSCEIVER MODULE

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

- Set Condition:
Bus messages not received from the Intrusion Transceiver Module for approximately two to five seconds.





VERIFY DTC IS ACTIVE
1. Turn the ignition on.
2. With the scan tool, read the active DTCs.

Does the scan tool display; U0168-00-LOST COMMUNICATION WITH INTRUSION TRANSCEIVER MODULE as Active?

Yes

- Perform the U0168-00-Lost Communication with Intrusion Transceiver Module.

No

- Perform the Stored Lost Communication DTCs diagnostic procedure. Stored Lost Communication DTCs
