U0146-00

U0146-00-LOST COMMUNICATION WITH CENTRAL GATEWAY

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Body Control Module (BCM) is configured correctly.

- Set Condition:
Bus messages not received from the Body Control Module (BCM) for approximately two to five seconds.





CHECK FOR AN ACTIVE DIAGNOSTIC TROUBLE CODE (DTC)
1. Turn the ignition on.
2. With the scan tool, read active DTCs.

Does the scan tool display this DTC as active?

Yes

- Perform the appropriate diagnostic procedure. Testing and Inspection

No

- Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
